DVB-S2X is the latest international standard for satellite broadcasting and an enhanced version of the DVB-S2 standard. This technology makes it possible to transmit more data using the same satellite capacity, improve picture quality, and reduce operating costs for broadcasters.
Why was this standard developed? The DVB-S2 standard was introduced in 2005 and has gradually reached its technological limits. As high-resolution video formats such as 4K and 8K have become more widespread, satellite operators have needed more efficient ways to transmit large amounts of data. The DVB-S2X standard, finalized in 2014 and now being increasingly adopted, addresses these requirements.
Key Technical Advantages
- Up to 51% higher efficiency: thanks to more efficient modulation and advanced signal processing techniques, DVB-S2X can deliver significantly more data within the same satellite bandwidth compared with DVB-S2.
- Advanced modulation schemes up to 256APSK: while DVB-S uses QPSK with four signal states and DVB-S2 supports modulation schemes such as 8PSK and 32APSK, DVB-S2X adds higher-order modes including 64APSK, 128APSK, and 256APSK. These modes allow much more data to be transmitted within the available bandwidth when signal conditions are suitable.
- Improved performance in poor weather conditions: DVB-S2X can use ACM (Adaptive Coding and Modulation) to automatically adjust the modulation and coding parameters according to current signal conditions. During heavy rain or snowfall, for example, the system can switch to a more robust transmission mode to help maintain the link.
- Operation at lower signal-to-noise ratios (SNR): DVB-S2X supports transmission modes designed to operate under lower SNR conditions, allowing useful data to be recovered when the signal is too weak for some DVB-S2 configurations. This is particularly important for applications such as satellite internet on aircraft and ships.
- Channel bonding: DVB-S2X can combine multiple satellite carriers into a single logical data stream, allowing additional capacity to be used for high-bandwidth applications such as 8K video transmission.
Where Is DVB-S2X Used?
- 4K and 8K satellite TV: major providers around the world are gradually adopting the standard for their UHD platforms.
- Satellite internet: DVB-S2X is used in VSAT systems, corporate networks, and high-capacity satellite communication links.
- Connectivity on the move: the technology can be used to provide internet and TV services on trains, aircraft, and ships.
What Does DVB-S2X Mean for Users?
The standard provides backward compatibility at the receiver level. This means that a receiver with DVB-S2X support can also receive channels transmitted using DVB-S and DVB-S2.
However, older satellite receivers, including HD models that support DVB-S2, cannot receive channels transmitted using DVB-S2X unless they have specific DVB-S2X support.
When choosing a new satellite receiver, it is therefore worth checking whether it supports DVB-S2X. This will help ensure that your receiver is ready for the growing use of the newer satellite broadcasting standard.
